Powerful 1 HP 120V motor

Adjustable upper/lower ball bearing blade guide system

Large 21-3/8" x 15-5/8" tilting table with rack & pinion adjustment

Flexible LED light increases workpiece visibility Belt tension adjustment knob

Rack & pinion height adjustment system

Circle cutting guide for diameters up to 27-1/2"

Dust chute accepts 2", 3" and 4" dust collector hoses

Comes complete with cast aluminum miter gauge, rip fence with 5" high face, push stick, adjustment wrench and hex. keys

Specifications

• MODELKC-1402FX
• CUTTING CAPACITY FRAME TO BLADE14"
• MAXIMUM DEPTH OF CUT8-3/4"
• TABLE SIZE21-3/8" x 15-5/8"
• TABLE HEIGHT FROM FLOOR40-1/2"
• BLADE SIZE 100-5/8" x (1/8" - 1") x 0.025"
• MOTOR1 HP
• AMPERAGE9.5 Amp.
• VOLTAGE120V, 1 phase, 60 Hz
• SPEEDS2 (1476, 3280) SFPM
• ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT30" x 22-3/4" x 67-3/4" / 166 lbs
• PACKAGING DIMENSIONS (LXWXH) / WEIGHT50-7/8" x 22-7/8" x 18-3/8" / 170 lbs
• UPC7 72995 01636 5
