3. Reset
Resetting the saw yourself is easy. Simply replace the blade and affordable brake cartridge and your saw is operational. The entire reset process takes less than five minutes.
Specs
Motor: (all 60Hz, TEFC):3, 5 & 7.5 HP available
Cabinet footprint:20" W x 25" D
Cast iron table:24" W x 30" D
Cast iron table (w/ extension wings):44" W x 30" D
Extension wings:10" W x 30" D each
Extension table 36 in:24" W x 30" D
Extension table 52 in:40" W x 30" D
Weights - table saw only:530 lbs
Weights - w/ 36 in fence systems:635 lbs
Weights - w/ 52 in fence systems:685 lbs
Shipping weight (approx.):640 lbs (table saw only)
Blade diameter:10"
Blade tilt:Left
Blade kerf:0.118" (3mm)
Blade plate thickness:0.078" (2mm)
Max. depth of cut, blade at 0º:3 1/8"
Max. depth of cut, blade at 45º:2 1/4"
Max. rip, right of blade - 36 in:36 1/2" (w/ optional 36" rails)
Max. rip, right of blade - 52 in:52 1/2" (w/ optional 52" rails)
Max. rip, left of blade:12 1/2"
Dado diameter:8" (requires a separate brake cartridge and insert)
Dado max. width:13/16"
Arbor diameter at blade:5/8"
Overall saw dimensions:44" W x 34" D x 34" H
Overall saw dimensions 36 in:69 1/4" W x 36 1/2" D x 34" H
Overall saw dimensions 52 in:85 1/4" W x 36 1/2" D x 34" H
